Wire Braid Hydraulic Hose EN857 2SC
Inner tube: Nitrile
Reinforcement: One or two braid of high-tensile steel wire
Cover: Black Neoprene Blend
Temperature Range:－40°F to 212°F(－40℃to 100℃)
Application standards: SAE J517 R16S, ISO 11237 2SC
Application: High pressure service with tight bends for petroleum and water-based hydraulic fluids. Excellent impulse performance and flexibility exceeding SAE100R1/SAE 100R2 and SAE 100R16 standards. Hose has compact dimensions tighter bend radius than 1SN/2SN hose for ease of assembly routing in machinery applications.
| 2SC | ||||||||||||
| 2SC-04-06 | -4 | 6.3 | 1/4 | 6.1 | 6.9 | 10.6 | 11.7 | 14.2 | 5800 | 23200 | 75 | 0.19 |
| 2SC-05-08 | -5 | 8.0 | 5/16 | 7.7 | 8.5 | 12.1 | 13.3 | 16.0 | 5076 | 20300 | 85 | 0.22 |
| 2SC-06-10 | -6 | 9.5 | 3/8 | 9.3 | 10.1 | 14.4 | 15.6 | 18.3 | 4785 | 19140 | 90 | 0.28 |
| 2SC-08-13 | -8 | 12.7 | 1/2 | 12.3 | 13.5 | 17.5 | 19.1 | 21.5 | 3990 | 15950 | 130 | 0.36 |
| 2SC-10-16 | -10 | 16.0 | 5/8 | 15.5 | 16.7 | 20.5 | 22.3 | 24.7 | 3625 | 14500 | 170 | 0.41 |
| 2SC-12-19 | -12 | 19.0 | 3/4 | 18.6 | 19.8 | 24.6 | 26.4 | 28.6 | 3120 | 12470 | 200 | 0.54 |
| 2SC-16-25 | -16 | 25.4 | 1 | 25.0 | 26.4 | 32.6 | 34.3 | 36.6 | 2390 | 9570 | 150 | 0.74 |
| Remark:1MPa=145PSI | ||||||||||||
