SAE 100R6
Inner tube: Oil resistant synthetic rubber
Reinforcement: One textile braids
Cover: Black oil & abrasion resistant synthetic rubber
Temperature Range: —40℃ to 135℃
| SAE 100R6 Technical Specifiction | ||||||||
| Product Number | Norminal ID | OD | W.P. | B.P | Min B.R. | Weight | ||
| mm | in | mm | PSI | PSI | mm | Kg/m | ||
| R6-05 | 4.8 | 3/16 | 11.1 | 493 | 1972 | 51 | 0.10 | |
| R6-06 | 6.4 | 1/4 | 12.7 | 406 | 1624 | 64 | 0.13 | |
| R6-08 | 8.0 | 5/16 | 14.3 | 406 | 1624 | 76 | 0.15 | |
| R6-10 | 9.5 | 3/8 | 15.9 | 406 | 1624 | 76 | 0.18 | |
| R6-13 | 12.7 | 1/2 | 19.8 | 406 | 1624 | 102 | 0.26 | |
| R6-16 | 16.0 | 5/8 | 23.0 | 348 | 1392 | 125 | 0.31 | |
| R6-19 | 19.0 | 3/4 | 26.6 | 247 | 988 | 140 | 0.47 | |
| R5-25 | 25.4 | 1 | 32.0 | 247 | 988 | 150 | 0.71 | |
